Safety Label Location—XUV590 S4 (Bench Seat)

MXT020162-UN-24MAY17

A - Help Prevent Injury when Dumping Loads M165565 (Machines with Power Lift)

B - Avoid Injury or Death from Rollover or Falling Off M165375

C - Read Operators Manual, Service Battery SU49461

D - Avoid Injury From Battery Gases and Acid M133159

E - Protective Structure Safety and Certification UC13991

F - Avoid Injury from Fire M165368

G - Avoid Injury M160658 (On Optional Front Rack)

H - Avoid Injury or Death from Falling Off M165365

I - Avoid Injury or Death from Rollover or Falling Off M168539

J - Read Operators Manual, Jacking Point SU48175

K - Avoid Injury From Equipment Fires M165273

L - Avoid Injury or Death from Rollover or Falling Off M165362
