Emptying Cargo Box

Raising a loaded cargo box changes the center of gravity. Keep vehicle a safe distance from the edge of ravine or drop-off when raising cargo box to empty.

A loaded cargo box can be very heavy. Do not attempt to manually raise a loaded cargo box. Unload cargo box before raising it by hand.

MXAL43175
MXAL43175-UN-19MAR13

  1. Back up machine to dump site.

  2. Park the machine safely. (See Parking Safely in SAFETY.)

  3. Open tailgate.

  4. Raise cargo box to dump load.

  5. Lower cargo box when empty.

  6. Close tailgate. Do not drive machine with cargo box in raised position.

BB87125,0000D6D-19-20130514
