Approved Tractors for 540 Loaders
All tractors with SOUND-GARD ® Body, except 5000 Series, are not approved for 540 Loaders. All tractors except 5000 Series require side frames (tractor equipment.) |
|
CAUTION:
To help prevent personal injury or death caused by tractor rollover, be sure tractor is equipped with rollover protective structure (ROPS).
| Tractors Approved for 540 Loaders | ||||
|---|---|---|---|---|
| Tractor Model Series | ||||
| 5000 | 55 | 50 | 40 | 30 |
| 5200 | 2155 | 2150 | 1040 | 830 |
| 5200 MFWD | 2155 MFWD | 2150 MFWD | 1140 | 1030 |
| 5210 | 2255 | 2350 | 1640 | 1130 |
| 5210 MFWD | 2355 | 2350 MFWD | 1840 | 1530 |
| 5300 | 2355 MFWD | 2550 | 1840 MFWD | 1630 |
| 5300 MFWD | 2355N | 2550 MFWD | 2040 | 1830 |
| 5310 | 2355N MFWD | 2040 MFWD | 2030 | |
| 5310 MFWD | 2555 MFWD | 2240 | 2130 HFWD | |
| 5400 | 2240 MFWD | |||
| 5410 | ||||
| 5410 MFWD | ||||
| 5500 | ||||
| 5500 MFWD* | ||||
| 5510 | ||||
| 5510 MFWD* | ||||
| * To help prevent damage to the 540 Loader Without Mechanical Self-Level when used on 5500 MFWD and 5510 MFWD Tractors: 1. Use only for light duty applications. 2. Do not exceed tractor ballast requirements shown in this section. |
||||
| MFWD - Mechanical Front Wheel Drive HFWD - Hydraulic Front Wheel Drive |
||||
|
Sound-Gard is a registered trademark of Deere & Company | AG,WX20570,3 -19-20MAY98-1/1 |
