Removing Material from a Pile With a Grapple

IMPORTANT: Using the grapple teeth to dig material out of a pile will damage the grapple or loader. The grapple is designed only to clamp material in a bucket. Use the bucket to break material loose.

1. If possible, remove material from the top of the pile first.

2. Use loader bucket to break material loose. Equip the bucket with tines for better loosening action in packed material.

3. After material is loosened, close grapple.

W12370
