Rear Ballast Requirements
Ballast given is minimum required for an 1800 mm (71 in.) or greater rear tread setting. For tread settings less than 1800 mm (71 in.) use an additional 320 kg (700 lb) per wheel. See your tractor Operator's Manual to add ballast to rear wheels. |
|
CAUTION:
To help prevent personal injury or death from tractor/loader rollover, add recommended amount of ballast to tractor. The amount of ballast listed is the minimum required for normal loader operation. For some operations, additional ballast may be required to maximize stability.
| Minimum Ballast Requirements (Per Wheel) | ||
|---|---|---|
| Tractor | 721 Loader | 726 Loader |
| 2520 | 180 kg (400 lb) | |
| 3020 | 900 kg (1985 lb) | |
| 4000 | 90 kg (200 lb) | 550 kg (1213 lb) |
| 4020 and 4230 | None | 550 kg (1213 lb) |
| 4055, 4255, and 4455 | None | 210 kg (463 lb) |
| 6600, 6800, 7200, and 7400 | None | 425 kg (937 lb) |
| All Other Tractors | None | 150 kg (331 lb) |
OUO6038,000020C -19-13DEC00-1/1 |
