Vertical Load

The axle load of the tractor will change due to the vertical load of the sprayer draw-hook on the tractor. However, the permissible load on axle and tires must not be exceeded (see Section "Wheels and tires"). This must be checked when mounting the tractor tires. If the front axle is unstable, front weights must be fitted to retain control of the tractor. When applying liquid fertilizers, bear in mind that their density is higher!

AG,WZ00009,631 -19-02MAR01-1/1
