Exit Lighting

To allow the operator to exit the forage harvester, the two row finder lights and the ladder light (from SN 508100) will remain on for 180 seconds after the road lights are turned off and the ignition key is removed.

Exit lighting is activated anytime when the road lights are used five minutes prior to turning off the ignition key.

Overriding the exit lighting is possible by pressing the quick stop switch prior to taking off the key or by cycling again the ignition switch after having turned it off. This will disable the exit lighting and thus the row finder lights will not be turned on.

OUCC002,00020ED -19-03NOV05-1/1
