Buzzer Alarm Inside The Cab

There are different operating modes for the audible alarm (buzzer) to provide acoustic notification and system warning information.

1. Continuous mode
2. Temporary mode (buzzer will sound for 5 seconds)
3. 5 short beep mode
4. Activate / Deactivate notification mode

• Activate notification: 1 short beep
• Deactivate notification: 2 short beeps

If the following conditions are met the audible alarm (buzzer) will sound in Continuous Mode:

• When a red stop light diagnostic trouble code information is received over the CAN Bus
• When moving the multi-function lever in forward position with the parking brake applied
• When turning on the turn signal switch and it stays in this position for longer than 2 minutes
• When the metal detector is in tripped mode and main clutch is still engaged

If the following conditions are met the audible alarm (buzzer) will sound in Temporary Mode:

• When an amber warning light diagnostic trouble code information is received over the CAN Bus
• When pressing the quick stop switch during powr savr operation

If the following conditions are met the audible alarm (buzzer) will sound in 5 Short Beep Mode:

• When a fault indicator light diagnostic trouble code information is received over the CAN Bus

If the following conditions are met the audible alarm (buzzer) will sound in Activate / Deactivate Notification Mode:

• Activate / deactivate row guidance
• Activate / deactivate area counter (if set in corresponding OBD address)
• After successfully resetting to factory settings

OUZXMAY,0000462 -19-14SEP04-1/2

• During self test at first power up

NOTE: When functions are automatically deactivated by the electronic system, the audible alarm will be controlled in the "deactivate notification mode".

OUZXMAY,0000462 -19-14SEP04-2/2
