The grain screen separates straw residue from grain.

If it is excessively open there will be a great deal of chopped straw in the grain tank.

If it is excessively closed there will be a great deal of grain in the tailings and, therefore, a great deal of cracked grain in the grain tank.

NOTE: See the charts in "Combine Settings" in this Section for initial adjustment values.
