ENG (Engine) Oil Pressure

Red light on and buzzer pulses if oil pressure drops below 2 bar (25 psi). Stop engine and check oil level, lines and filter.

NOTE: This sensor also provides the interlock so the combine hydraulic functions will not operate unless the engine is running.

If the light still stays on, see your John Deere dealer.

H52377

AG,OUO1035,766 -19-25JUN99-1/1
