OMZ92984: 6650, 6750, 6850 and 6950 Self-Propelled Forage Harvesters (504992- ), Block File: ZX_OMSPFH001415_19

Provisional Cleaning by Tapping

As a provisional measure during operation, tap element on palm of hand or on a flat soft surface.

ZX,OMSPFH001415 -19-01NOV91-1/3

Cleaning with Compressed Air

Direct compressed air through filter in opposite direction of arrows on filter [maximum pressure 200 kPa (2 bar; 30 psi)].

ZX,OMSPFH001415 -19-01NOV91-2/3

Washing the Filter

IMPORTANT: Never wash element in fuel or strong detergents. Never install a wet or damp element.

Hold filter element under running water to remove any coarse dirt.

Soak element for approx. 15 min. in lukewarm water, using a mild non-sudsing detergent. Wash element.

Rinse element in warm water [pressure not exceeding 200 kPa (2 bar; 28 psi)]. Shake filter and allow to dry.

ZX,OMSPFH001415 -19-01NOV91-3/3
