Four-Wheel Drive (Optional)

CAUTION: Ground speed will increase when disengaging four-wheel drive and will decrease when engaging four-wheel drive.

IMPORTANT: To prevent damage to the hydrostatic system, do not switch four-wheel drive on or off while driving combine in third gear at maximum travel speed. Reduce speed to less than 1/2 of maximum.

Turn four-wheel drive off before going down a steep grade.

Switch (A) controls the two-speed four-wheel drive system. Press either switch once to engage and once to turn off. A lighted indicator above each switch is on when the drive is engaged.

Press the bottom switch (turtle) for lower travel speeds and the top switch (rabbit) for higher travel speeds.

NOTE: For best overall performance it is recommended that the two-speed four-wheel drive be left in the low (turtle) speed mode. This will allow the machine to operate at maximum torque capacity.

A-Four-wheel drive switch

ZX08994,0000123 -19-05MAR02-1/1
