Clock SwitchNOTE: Reset the digital clock if the battery was disconnected or the battery switch was moved to OFF position. When this switch is pressed, the time of day appears in the bottom line. No icon will be displayed with the real time clock. The colon symbol between the second and third digits is turned on to separate the hours and minutes. The colon symbol flashes at a rate of 60 times per minute. Press the clock switch and the time of day will no longer be displayed. Setting Time on Clock 1. Press and hold simultaneously the clock and calibration switches for a minimum of 1 second. This will result in the time of day information being displayed and the "hours" digits will flash2. Press and hold either the up or down arrow key switch, the hour digits will continuously change values until released. 3. Once desired hour information has been set, press the clock switch. The "hour" digits shall no longer flash and the "minute" digits shall flash. 4. Press and hold either the up or down arrow key switch, the minute digits will continuously change values until released. 5. Once desired minute information has been set, press the clock switch momentarily. The "minute" digits shall no longer flash and the "hour" digits shall flash. 6. To exit the clock setting mode and save the clock setting changes, press the enter switch. To calibrate clock enable / disable and clock display mode use the following address:
|
|
