Engine Operating Hours And Cutterhead Operating Hours Switch

When the engine hours / cutterhead hours switch is pressed the total accumulated engine hours and the engine speed icon will be displayed on the second (middle) line of the display. At the same time the accumulated cutterhead hours and cutterhead speed icon will be displayed on the third (lower) line of the display.

The hours for both functions will remain displayed for a maximum of 10 seconds after the engine hours / cutterhead hours switch has been released. When 10 seconds have elapsed, the second (middle) and third (lower) lines will return to their previous mode of operation. If the switch is pressed again prior to the 10 seconds elapsing, the second and third lines will return to their previous mode of operation.

OUZXMAY,00003C3 -19-05MAY02-1/1
