Brake Fluid for Brake System

IMPORTANT: Use only brake fluid meeting SAE Standard J 1703 (DOT 3 or DOT 4).

Capacity:

• Complete system 1.0 L (0.26 U.S. gal)
• Reservoir 0.5 L (0.13 U.S. gal)

A-L.h. guard - spout ring gear
B-Brake fluid reservoir
C-Reservoir cap with float

OUZXMAY,0000561 -19-14SEP02-1/1
