Service Machine Safely
Practice Safe Maintenance
ˇ Understand service procedure before doing
work. Kep area clean and dry.
ˇ Never lubricate or service machine while it
is moving. Keep safety devices in place
and in working condition. Keep hardware
tight.
ˇ To prevent them from getting caught, keep hands, feet, clothing, jewelry, and long hair away from any moving parts.
ˇ Before servicing machine, lower attachments to the ground. Disengage all power and stop the engine. Move hydraulic lift levers back and forth to relieve pressure. Lock park brake and remove the key. Let tractor cool.
ˇ Securely support any machine elements that must be raised for service work.
ˇ Never run engine unless park brake is set and locked.
ˇ Keep all parts in good condition and properly installed. Repair damage immediately. Replace worn or broken parts. Remove any buildup of grease, oil, or debris.
ˇ Disconnect battery ground cable (-) before making adjustments on electrical systems or welding on tractor.
ˇ Unauthorized modifications to the machine may impair its function and safety.
Wear Appropriate Clothing
ˇ Wear close fitting clothing and safety equip-ment appropriate for the job.
ˇ Loud noise can cause impairment or loss of
hearing, wear a suitable protective device
such as earplugs.
ˇ Do not wear radio or music headphones while operating the machine. Safe operation requires your full attention.
Stay Clear Of Rotating Drivelines
Entanglement in rotating driveline can cause
serious injury or death:
ˇ STOP the engine and be sure PTO driveline
is stopped before getting near it.
Handling Waste Product And Chemicals
ˇ Waste products, such as, used oil, fuel, coolant, brake fluid, and batteries, can harm the environment and people.
ˇ DO NOT use beverage containers for waste
fluids-someone may drink from them.
ˇ See your local Recycling Center or John Deere dealer to learn how to recycle or get rid of waste products.
Avoid High Pressure Fluids
ˇ Escaping fluid under pressure can penetrate the skin causing serious injury. Avoid the hazard by relieving pressure before disconnecting hydraulic or other lines. Tighten all connections before applying pressure.
ˇ Search for leaks with a piece of cardboard. Protect hands and body from high pressure fluids.
ˇ If an accident occurs, see a doctor immediately. Any fluid injected into the skin must be surgically removed within a few hours or gangrene may result. Doctors unfamiliar with this type of injury should reference a knowledgeable medical source. Information may be obtained in the United States and Canada only by calling 1-800-822-8262.
