Service Machine Safely
Practice Safe Maintenance
ˇ Understand service procedure before doing work. Keep area clean and dry.
ˇ Never lubricate, service, or adjust machine while it is moving. Keep safety devices in place and in working condition. Keep hardware tight.
ˇ To prevent them from getting caught, keep hands, feet, clothing, jewelry, and long hair away from any moving parts.
ˇ Before servicing machine, disengage all power and stop the engine. Let engine cool.
ˇ Securely support any machine elements that must be raised for service work.
ˇ Keep all parts in good condition and properly installed. Fix damage immediately. Replace worn or broken parts. Remove any buildup of grease, oil, or debris.
ˇ Unauthorized modifications to the machine may impair its function and safety.
Wear Appropriate Clothing
ˇ Wear close fitting clothing and safety equipment appropriate for the job.
ˇ Loud noise can cause impairment or loss of hearing, wear a suitable protective device such as earplugs.
ˇ Do not wear radio or music headphones while servicing the machine. Safe service requires your full attention.
Avoid Injury From Contacting Blades
BEFORE YOU DISMOUNT TO UNPLUG OR ADJUST CUTTING UNITS:
ˇ DISENGAGE reel drive by moving the mow/transport lever to the Transport position.
ˇ LOWER cutting units to the ground.
ˇ Wait for reels and all moving parts to STOP.
BLOCKED OR STALLED CUTTING CYLINDERS:
ˇ Keep all parts of the body away from the cutting edges. Residual hydraulic pressure in the system can cause cutting cylinder rotation when the blockage is released.
BLADES ARE SHARP:
ˇ Use a long-handled brush when applying reel-sharpening compound.
ˇ Keep hands, feet and clothing away from cutting units when engine is running.
ˇ Keep bystanders away from cutting units when adjusting or servicing.
ˇ Always wear gloves when manually rotating reel. Manually rotating one reel can cause another reel to rotate.
Prevent Fires
ˇ Never remove fuel cap, or add fuel with engine
running or hot. Allow engine to cool for several
minutes.
ˇ Never store equipment with fuel in the tank inside
a building where fumes may reach an open flame or spark.
ˇ Allow engine to cool before storing in any enclosure.
ˇ To reduce fire hazard, keep engine free of grass, leaves, or excessive grease.
ˇ Do not run engine in a closed building without adequate ventilation.
Handling Waste Product and Chemicals
ˇ Waste products such as used oil, fuel, coolant, brake fluid, and batteries, can harm the environment and people.
ˇ DO NOT use beverage containers for waste fluids - someone may drink from them.
ˇ See your local Recycling Center or John Deere dealer to learn how to recycle or get rid of waste products.
ˇ A Material Safety Data Sheet (MSDS) provides specific details on chemical products: physical and health hazards, safety procedures, and emergency response techniques. See your John Deere dealer for the MSDS on chemical products used with your machine.
